- Reliable and robust working or holding brake
- Ideal for modular systems
- Available in version C (adjustable braking torque) or N (T)
(fixed braking torque with or without speedometer holes)
- Protection class IP 54 when mounted under an engine fan cover
- Ambient temperature -20°C up to +40°C
Specifications
Size
Braking torque [Nm]
Outer diameter [mm]
Height [mm]
08
5
85
38,3
10
10
105
47,7
13
20
130
53,1
15
40
150
60,3
17
60
170
69,8
20
100
195
80,4
23
150
225
89,8
26
250
258
98,9
30
400
306
104,5
40
1000
400
120,6
Warranty Period
Warranty Period: 1 Year
