| Selection table | ||||
| Type | Rated voltage(V) | Ex-Mark | Lamp color | Weight(kg) |
| BBJ-R | 220V/230V AC 50/60Hz 24V DC/AC | Ex d ib ⅡC T6 Gb Ex tD ibD A21 IP66 T80℃ | Red | 3 |
| BBJ-B | Blue | |||
| BBJ-Y | Yellow | |||
| BBJ-G | Green | |||
| The light fitting is supplied with Ex type stopping plug and Ex cable gland is on request. | ||||
| Technical parameters | |
| Conformity to standards | IEC60079, EN60079, GB3836, GB12476, CCSstandard |
| Ambient temperature | -40℃~+55 |
| Light source | LED module |
| Sound intensity | ≥110dB(R=1m) |
| Flash frequency | 150 times/min |
| Degree of protection | IP66 |
| Corrosion-proof | WF2 |
| Cable entry | 1×M25×1.5plug (Aluminum alloy). DQM-Ⅱ/Ⅲ Ex db, M25×1.5 gland (Nickel plated brass) is recommended. Suitable for Φ12.5~Φ20.5mm cable |
| Terminal | 3x1.5~2.5mm2 |
